12V 50W Load Resistors – 6 Ohm (Twin Pack)
These IP67-rated dummy load resistors are designed to simulate the current draw of standard 21W halogen globes, allowing you to run LED lights on vehicles with electronic systems that aren't LED-compatible. Ideal for indicator and brake light circuits.
Product Details:
- 12 Volt Operation
- Power Rating: 50 Watts
- Resistance: 6Ω (Ohms)
- Includes: 2 x Load Resistors (Blister Twin Pack)
- Mounting: Dual screw points for secure installation
- IP67 Rated: Waterproof and dustproof
Important Usage Notes:
- Warning: Resistors get extremely hot during use – up to 170°C
- Must be mounted on metal surfaces to dissipate heat safely
- Do NOT mount on plastic, painted surfaces, wiring, or near hoses
- Use crimp connectors to wire the resistor inline with the lamp wiring (not to vehicle chassis)
Wiring Instructions:
- Indicator Circuit: Connect one lead to Yellow (positive), one to White (ground)
- Brake Circuit: Connect one lead to Red (positive), one to White (ground)
Correct Fitment:
- Always wire between the input wires of the lamp
- Never connect the resistor directly to vehicle chassis
- Mount securely using screw holes to metal frame
